Please Note:

• This kit will maintain factory fitted amplifier, and only suits vehicles equipped with Factory Navigation from factory.
• 2 Antenna adapter variants are supplied as certain vehicles will have one or the other.
• Only one will be required for installation.

PATCH LEAD This interface connects a compatible car stereo with a joystick input (blue  line-in mini-jack) or wire input on the back of the unit to the existing stalk/steering wheel controls of the vehicle.

Universal head unit connection lead for:

• Alpine (3.5mm jack)
• Beat (single wire connection)
• Chinese / Xtrons / 3 wire unbranded units (3 wire connection)
• Clarion (3.5mm jack)
• JVC (3.5mm or single wire)
• Kenwood (single wire)
• LG (3.5mm jack)
• Nakamichi (single wire connection)
• Panasonic  (single wire but NOT AV units)
• Philips (single wire connection)
• Pioneer (3.5mm jack)
• Sony (3.5mm jack)
• Zenec  (single wire)
• Other Chinese SWC learning head units

Important Patch Lead Notes:

• You can simply cut the loops / wires to select which brand you are fitting. Supplied with instruction sheet
• This patch lead CANNOT be used for Blaupunkt / Parrot / Becker / JVC KW-AVX head units / Older Kenwood units with the DIN plug. For those models you need to purchase the lead from the add-on options.

Important Fascia Notes:

• The fascias are made to suit industry standard sized stereos such as Pioneer, Kenwood, Sony, Alpine, JVC etc, NOT INCLUDING China units or unbranded units.
• China units have a reputation to be over sized and may require modification to the fascia to allow it to fit.
• We do not take any responsibility for China units not fitting as they are not industry standard size.
• Branded units come with a mounting cage and in most cases fit depending on the car.
• If the one supplied with the stereo does not fit the fascia then you must purchase a universal version slightly smaller part number.
• China units in general never come with a mounting cage.  Click here for CT23UN01 UNIVERSAL Mounting Cage

Technical Assistance:

• If in doubt please email us with your vehicle details and we will confirm what you require.

IMPORTANT NOTE:

Please make sure that is the correct Fitting Kit for your car by firstly checking to see if your make, model and year of car is listed in the description. Secondly by checking to see if the connection & Shape in the picture listed is the same as you have in your vehicle. We try to provide upto date information as possible. If you are unsure please contact Customer Service on 020 8875 2525 and we will be happy to help you.
