GM-6500F 4 Channel Bridgeable Amplifier Configure the perfect setup. Start here.

Designed to fit both cosmetically and technically with our subwoofers, the GM-6500F amplifier gives you total installation freedom and no distortion.
With a one-body heat sink and gain adjustment of up to 6.5V, you can turn your in-car audio experience into the sound staging environment that you’re looking for.

Pioneer GM-6500F 4-channel amp allows you to drive multiple speakers and subwoofers, it’s also bridgeable to power a single sub.

Pioneer GM-6500F Specifications:

• Maximum Output Power 4 x 190 W (4 ohms) / 2 x 380 W (4 ohms bridged)
• CEA 2006 Power (THD + N = 1%) 60 W RMS X 4
• Continuous power output (RMS)
• 14.4V (20Hz-20kHz/4 ohms): 4 x 60 W / 2 x 180 W (bridged)
• 14.4V (20Hz-20kHz/2 ohms): 4 x 86 W
• Load impedance capability    4 ohms
• Frequency response (+0dB , -3dB) 10Hz ~ 70k  Hz
• Distortion < 0.03  %
• S/N ratio  > 90  dB
• LPF 80 Hz (-12 dB/oct)
• HPF 80 Hz (-12 dB/oct)
• RCA terminals  Yes (input/output)
• Speaker Terminals Screw-type
• High Voltage Input Capability 200 mV - 6.5 V
• Input level control 0.8 - 26 V
• Max. current consumption (A/4ohms) 32 A
• Chassis size (W x H x D) 289 x 62 x 349  mm
• Unit weight 3,3  kg
