Kenwood DPX-303 Double Din MP3/WMA/AAC CD-Receiver

Kenwood DPX303 Key Features:

• Double DIN Size Fixed Faceplate
• 4 Line Mono Colour Full dot LCD Display
• 50W x 4, 2 RCA Pre-outs
• System Q-Ex, System E's+
• MP3/WMA/AAC-Decoder, 24-Bit Digital Audio Converter
• Front AUX input with slide protection cover
• Ready for Bluetooth Hands-Free Profile / Audio Profile
• Blue Illumination + Emotional Illumination Effect

• DIN Size 2 DIN
• Faceplate Mechanism Non (Fixed)
• Security Code Function
• Key Illumination Selectable: blue, red or green
• Rotary Encoder & Control Knob
• Operation mode 4-Directions + Push + Rotary
• Attenuator with Smooth Volume Return
• Touch Sensor Tone
• Digital Clock (24H)
• All-off Select (20/40/60 minutes)
• ISO connector

• Display Type LCD Display
• Display Layout 4 line, Ful dot
• Display Illumination blue
• Spectrum Analyzer
• Dimmer Control 2 steps - Automatic
• Auto dimmer control function (on/off)
• Positive/negative switchable
• Display Off Mode
• Demo Mode

• RDS (PI, PS, AF, TI, Clock)
• Radio Text (RDS)
• Program Type Function (PTY)
• Enhanced Other Networks Function (EON)
• K3I - Clean Reception Tuner
• FM Reception
• AM (MW/LW) Reception
• Presets 24 Presets (18FM / 3LW / 3MW)
• Automatic Memory Entry (AME)
• Up/Down Seek Tuning
• Tuning mode (Auto1 / Auto2 / Manual)
• FM Stereo / Mono Selector

• CD-R/RW Compatible
• MP3 Playback with ID3 Tag Display
• WMA (Windows Media Audio) Playback
• AAC (Advanced Audio Coding) Playback
• CD Text Support
• Supreme
• D.A.C. processing 24 bit (Burr Brown)
• 0 bit Mute
• Random Function (Track/Disc)
• Repeat Function (Track/Disc)
• Scan Function (Track/Disc)
• External Media Control Features
• Dual Changer Control (CH1, CH2 & AUX)
• CD Text Ready with Compatible KENWOOD Units
• Disc & Track Repeat
• Disc & Track Scan
• Disc & Track Random Play
• Direct Access
• Disc Name Preset Play (DNPS)
• Bluetooth Handsfree
• Bluetooth Audio Streaming
• iPod Control with KCA-iP500

DPX303 Audio Features:

• Maximum Output Power 50W x 4
• MOSFET Power IC
• Auxiliary input 1 RCA
• Auxiliary input , Front
• Auxiliary Type Mini-jack
• Pre-out 2 RCA
• Pre-out Output Level 2.5V
• Preout Rear / Subwoofer Switchable
• Subwoofer Reference Level Adj.
• Built-In Amplifier Cut-Off
• Dual-Zone Source & Volume Control
• Dual-Zone (FRONT / REAR Switchable)
• Source Tone Control & Memory Bass / Mid / Treble
• Balance/Fader/Loudness Control
• Att.(-20dB) with smooth Volume Return
• System Q_EX (Preset & Manual Sound Control)
• System E's+ (Built-in HPF & LPF)

DPX303 Connectivity:

• External Media Control Bus (5L)
• iPod I/F Control (5L-Bus)
• Bluetooth Control (5L-Bus)
• PS Amplifier Control System (5L-Bus) PS Amplifiers ('02 - '06)
• B.M.S.Control ('99-'03 Amps)
• Advanced B.M.S. Control ('02 Amps)
• OEM Wired Remote Control
• OEM Display Control
• Power Control (P.CON) wire
• External Amplifier Controle Wire
• 2-way (Tel/Navi) mute wire
• Dimmer control wire

DPX303 Cosmetics features:

• Front/edge Black Injection
• Dress plate Metalic Black
• Volume & operation knob or wheel Chrome Plated
• Preset key finish Black Injection
• Escution Black Injection
• Triangle Illumination Red
• Key illumination Selectable: blue, red or green
• Illumination Effect

DPX303 Tuner Specifications:

• FM Frequency Range 87.5MHz ~ 108MHz
• FM Frequency Step 50kHz
• FM Usable Sensitivity 0.7μV/75ohm (S/N 26dB)
• FM Quieting Sensitivity 1.6μV/75ohm (S/N 46dB)
• FM Frequency Response 30Hz ~ 15kHz (± 3dB)
• FM Sigal to Noise Ratio 65dB(MONO)
• FM Selectivity(DIN) over 80dB (±400kHz)
• FM Stereo Separation (1kHz) 35dB
• MW Frequency Range 531kHz ~ 1611kHz
• MW Frequency step 9kHz
• MW Usable Sensitivity 25μV (S/N 20dB)
• LW Frequency Range 153kHz ~ 281kHz
• LW Usable Sensitivity 45μV (S/N 20dB)

DPX303 CD Specifications:

• Laser Diode GaAIAs
• Digital Filter(D/A) 8 Times OverSampling
• Digital/Analogue Converter 1 Bit
• Spindle Speed 500 ~ 200rpm (CLV: 1 times)
• Wow & Flutter Below Measurable Limit
• Frequency Response 10Hz ~ 20kHz (±1dB)
• Total Harmonic Distortion 0.008% (1kHz)
• Sigal to Noise Ratio 105dB (1kHz)
• Dynamic Range 93dB
• MP3 Decoder Compliant with MPEG-1/2 Audio Layer-3
• WMA Decoder Compliant with Windows Media Audio
• AAC Decoder AAC-LC ".m4a" files

DPX303 Audio Specifications:

• Maximum Power 50W x 4
• Output Power (DIN45324,+B=14.4v) 22W x 4
• Preout Level 2500mV / 10kOhm,
• Preout Impedance 600Ohm
• Speaker Impedance 4Ohm ~ 8Ohm
• AUX Frequency Response 20Hz ~ 20kHz (±1dB)
• AUX Maximum Input Voltage 1200mV
• AUX Input Impedance 100kOhm
• Bass Tone Control 100Hz ±8dB
• Middle Tone Control 1kHz ±8dB
• Treble Tone Control 10kHz ±8dB

DPX303 General Specifications:

• Operating voltage 14.4V (11 ~ 16V Allowable)
• Current Consumption 10A
• Dimensions (WxHxD) 182 x 112 x 160mm
• Weight 1600gr
