General

• 5 Channel Operation
• Thermal Management Processor
• Parametric EQ
• Manual Time Correction
• Subsonic Filter
• Bass Management
• Phase Selector
• MOSFET Power Supply
• DC-DC PWM Power Supply
• Discrete Pre-Amp Stage
• Triple Darlington in Push-Pull Configuration
• Darlington Bi-Polar Outputs
• STAR Circuitry
• Auto Over-Current Protection
• Top Mounted Blue LED Power/Status Indicator
• Gold Plated RCA Input Connectors
• Gold Plated Power Screw Terminals
• Gold Plated Speaker Terminals
• Dual Sided Glass Epoxy PC Board

• Crossover Network: 6/12/18/24dB
• Crossover Frequency : 20 - 200Hz: 1/3 oct step (1/2ch, 3/4ch), 20 - 400Hz:
• 1/3 oct step (5ch), 20 - 200Hz: 1/12 oct step (6ch, LP/OFF)
• Subsonic Filter (Selectable): 20 - 50Hz, 1/6 oct step, slope: 6/12/18/24
• on/off
• Parametric EQ (Bands): 17 (Front: 5, Rear: 5, Center: 5, Subwoofer: 2)
• Parametric EQ (Frequency): 20 - 20kHz (1/6 oct step)
• Parametric EQ (Width (Q)): 0.5/1/2/3/4/5
• Parametric EQ (Level): ±9dB

• Heat Sink (WxHxD) in: 11-7/32¨ x 9-31/64¨ x 2-23/64¨
• Heat Sink (WxHxD) mm: 285mm x 241mm x 60mm
• Foot Print (WxHxD) in: 13-1/16¨ x 9-31/64¨ x 2-23/64¨
• Foot Print (WxHxD) mm: 332mm x 241mm x 60mm
